Product Overview
The EDAN iM3 Vital Signs Monitor is designed for spot-check, rounding, and continuous vital signs monitoring in clinical environments. It provides SpO₂ and non-invasive blood pressure (NIBP) measurement, with temperature available in select configurations. The iM3 features an 8-inch capacitive touchscreen, Wi-Fi and Bluetooth connectivity, extensive patient data storage, and support for adult, pediatric, and neonatal monitoring.
Product Features
- Measures SpO₂ and NIBP, with temperature options available by configuration.
- 8-inch color TFT LCD capacitive touchscreen with 800 × 480 resolution.
- Supports Monitor, Round, and Spot-Checking modes with extensive data storage.
- Built-in Wi-Fi, Bluetooth, USB, and network connectivity for clinical data workflows.
- Rechargeable lithium-ion battery supports portable use between patient locations.
| SKU/Catalog Number | MF-iM3 |
| Product Name | iM3 Vital Signs Monitor |
| Brand | EDAN |
| Manufacturer | EDAN |
| Model | iM3 |
| Product Type | Vital Signs Monitor |
| Parameters | SpO₂, NIBP |
| Optional Parameter | Temperature |
| Patient Types | Adult, Pediatric, Neonatal |
| Display | 8" Color TFT LCD Capacitive Touchscreen |
| Display Resolution | 800 × 480 |
| NIBP Method | Oscillometric |
| NIBP Modes | Manual, Auto, Continuous, Average |
| NIBP Measurements | SYS, DIA, MAP, PR |
| SpO₂ Measurement Range | 0%–100% |
| SpO₂ Resolution | 1% |
| SpO₂ Accuracy | Adult/Pediatric: ±2% at 70%–100%; Neonatal: ±3% at 70%–100% |
| Pulse Rate Range | 25–300 bpm with EDAN SpO₂ Module |
| Pulse Rate Resolution | 1 bpm |
| Work Modes | Monitor, Round, Spot-Checking |
| Wi-Fi | IEEE 802.11b/g/n, 2.4 GHz |
| Bluetooth | E-Link Bluetooth |
| USB Port | 1 |
| Micro USB Port | 1 |
| Network Interface | 1 |
| Barcode Scanner | Optional |
| Battery Type | Rechargeable Lithium-Ion |
| Battery Capacity | ≥2400 mAh |
| Battery Operating Time | ≥3.5 Hours |
| Dimensions | 159 × 262 × 166 mm |
| Weight | <2.5 kg, Standard Configuration Without Accessories |
| Application | Vital Signs Monitoring |
